VOCE II performance, sold as the correct pair
The AV 3.0 II midrange pair is engineered for clarity through the vocal and instrumental band. A semi-pressed paper cone with cotton fibres, oversized neodymium motor, copper shorting ring and die-cast aluminium basket combine low distortion with useful output from a notably shallow chassis.
Current supplier-channel stock is available, subject to final allocation before dispatch.
Verified technical specifications
| Nominal diameter | 70 mm / 3 inch |
|---|---|
| Nominal impedance | 4 ohm |
| Minimum impedance | 3.2 ohm |
| Peak power handling | 100 W |
| Continuous power handling | 50 W |
| Sensitivity | 90 dB |
| Frequency response | 160-13,000 Hz |
| Voice coil | 26 mm CCAW on glass-fibre former |
| Magnet | Neodymium |
| Cone | Semi-pressed paper with cotton fibres |
| Outer diameter | 84 mm |
| Cut-out diameter | 73 mm |
| Mounting depth | 31.2 mm |
| Xmax | 1.4 mm |
What is included
2 x AV 3.0 II midrange drivers; 2 x black mesh metal grilles; Audison badges.
System design and protection
Audison’s VOCE II advanced manual gives a 300-500 Hz high-pass and a low-pass matched to the tweeter high-pass, both at 24 dB/octave, as active-system starting guidance. Final protection, phase, level and equalisation must be established in the vehicle.
This is a premium standalone component set, not a universal plug-and-play speaker kit. Correct amplification, crossover protection, polarity, mounting and acoustic tuning are required. For a passive VOCE II system, select the manufacturer-matched VOCE II kit or crossover rather than assuming a generic network is suitable.
Exact product identification
| Manufacturer | Audison |
|---|---|
| Range | VOCE II |
| Model | AV 3.0 II 3-inch Midrange Set |
| Supplier SKU | 69020021 |
| Selling unit | Pair / set |
Product identity, technical data and imagery were verified against the official Audison product page. The displayed South African price follows the supplier Recommended Retail policy; local supplier-channel stock is confirmed before dispatch.
