Product overview
The Audison VOCE II AVK 6 P II system is meticulously engineered to deliver dynamic and powerful audio performance. Integrating the AV 1.1 II Hi-Res Tweeter and the robust AV 6.5 P II Mid-Bass Component, this setup offers exceptional power handling up to 150W RMS, thanks to the 40 mm CCAW voice coil. The included AVCX 2P TW passive crossover is crafted from high-quality components, providing extensive tone controls and bi-amplification support for precise sound customization. Installation is facilitated by OEM-style and Faston connectors, making it adaptable to any vehicle setup.
Key features
- Hi-Res Audio Certified, Extending Up to 40 kHz: Delivers detailed high-frequency reproduction with improved off-axis response, ensuring exceptional performance even when the tweeter is not directly aligned with the listener, ideal for in-car installations.
- Tetolon Soft Dome: Optimized through advanced material characterization, laser vibrometer scanning, and simulations, providing a smooth, extended response with warm, natural sound reproduction.
- 1.1” (28 mm) CCAW Voice Coil: Lightweight and stable, eliminating transient compression and ensuring low distortion for clean, natural sound, even at high SPL levels.
- Powerful Neodymium Magnet: Designed for superior dynamic response and minimal distortion across the frequency range, enhancing clarity and precision.
- OEM-style and Faston connectors: Ensures maximum versatility for quick and easy installation in any vehicle, with no additional adapters needed.
- AIF (Any Install Faceplate) Technology: Offers total installation flexibility and significantly reduces setup time, with two faceplates and three mounting accessories included—perfect for any configuration. Includes two provided adhesive Audison logos, allowing for personalized placement to enhance branding and aesthetics.
- FEM-Optimized Faceplates: Enhance sound dispersion for a balanced and immersive audio experience from any listening angle.
- Mesh and Spoke Grilles Included: Both grille options ensure perfect in-car integration, combining aesthetics with performance.
Technical specifications
| Technical Specs LF | |
|---|---|
| Woofer Size | 165 mm (6.5 in) |
| Impedance | 4 Ohm |
| Power Handling – Peak | 300 W |
| Power Handling – Continuous | 150 W |
| Frequency Response | 45 – 7500 Hz |
| Voice Coil Diameter | 40 mm (1.57 in) |
| Magnet Material | HIGH DENSITY FLUX FERRITE |
| Magnet Size | 100 X 45 X 18 |
| Cone Material | SEMI-PRESSED PAPER |
| Crossover Type | Two Way Passive Crossover (Woofer Full/6dB Oct., Tweeter – 12dB/Oct.) |
| Crossover Level Adjustment | High Frequency Contour, Mid Frequency Contour, Bi-Amping, Hi Boost, Tweeter Level |
| Technical Specs HF | |
| Tweeter Size | 28 mm (1.1 in) |
| Frequency Response | 1000 – 40000 Hz |
| Power Handling – Peak | 180 W |
| Voice Coil Diameter | 28 mm (1.57 in) |
| Dome Material | TETOLON FIBRE |
| Electric-acoustic Specs LF | |
| Re | 2.9 Ohm |
| Fs | 66 Hz |
| Mms | 15.3 g |
| Cms | 0.28 |
| BL | 5.5 |
| Qms | 9 |
| Qes | 0.61 |
| Qts | 0.57 |
| Vas | 9.09 l |
| Le | 0.3 mH |
| Spl | 91 dB |
| Xmax | 4.95 mm (0.19 in) |
| Kit Tech Data | |
| Crossover Low-Pass | AVCX 2P TW: Woofer, Full/6dB Oct. |
| Crossover Hi-Pass | AVCX 2P TW: Tweeter, 12dB/Oct. |
| Crossover Cut Off | 3 kHz (HFC:ON2, MFC:ON, HiBoost:OFF, TW:0dB) |
| Cone Diameter | 128.3 mm |
| General | |
| Weight Woofer | 1.6 kg |
| Weight Tweeter | 0.1 kg |
| Weight Crossover | 0.42 kg |
| Dimensions | |
| Dimension A | 165 mm (6.5 in) |
| Dimension B | 140.8 mm (5.54 in) |
| Dimension C | 74.2 mm (2.92 in) |
| Dimension D | 69.8 mm (2.75 in) |
| Dimension B2 | 44.9 mm |
| Dimension D1 | 16.5 mm |
| Frequency Response | |
| Tweeter | Woofer |
What you are ordering
The exact Audison model shown above, SKU 69051034. Check the vehicle and system requirements before ordering OEM-fit or integration accessories.
