Product overview
- Film category: Vehicle Wraps
- Finish: Gloss Metallic
- Colour family: Green
Our Gloss Metallic vinyl wrap has a smooth, high-gloss finish and is crafted from the high-grade polymeric multilayered calendared vinyl film, complete with air release channels. Gloss Metallic wrap is durable and has good conformability; it’s stretchable enough to wrap around every edge and recessed area of your vehicle with ease. Gloss Metallic also uses a safe solvent polyacrylate adhesive, easy to install, and is gentle on car paint.
Specifications
Conformable polymeric material with stable color pigments. Suitable for complete car wrapping (or any other smooth or curved surface).
- Film Thickness: 0.14 mm
- Backing Liner Thickness: 0.13 mm
- Release Liner Thickness: 0.03 mm
- Total Thickness (with liner): 0.30 mm
- Note: Products that have “HD” letters in their SKU (product code) are with the plastic release liner (high-gloss films)
- Type of Film: Premium-grade polymeric multilayered hybrid vinyl film with air-release channels
- Width & Length: Standard roll size – 1.52m18m (59.8″708.6″, 4.98ft59ft, 1.66yd19.6yd)
- Series: 190 series
Adhesive & Release Liner
- Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000cps, thickness 12 μm dry
Storage
- Storing Period (Shelf Life): 2 years if stored in +10°C to +20°C, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
Performance
- Durability/Warranty: Datasheet (Click the link)
- Application: from +17°C to +18°C, usage from -45°C to +45°C
- Release Force (N/25mm): Standart: 0.10-0.30, Result: 0.17 (23℃,54%H)
- Initial Tack (g/25mm): Testing method: GB31125-2014, Standart 800-1500, Result: 840 (23℃,54%H)
- 180° Peel Strength (N/25mm): Testing Method: GB/T2792-1998, Standart ≥6.8, Result: 8.7 (23℃,54%H)
- Adhesion Strength: Testing method: GB/T4851-1998, Standart ≥60, Result 70 (No shifting)
- Aging (65℃, 7 days): Standart – High-temperature release without adhesive residue, result: no adhesive residue
- Aging (-65℃, 10 days): Standart – Low-temperature release without adhesive residue, result: no adhesive residue
- Recommended Application Tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, IRR heater
- Application Method: Standard methods for calendered films. No overstretching. Post heating
- Post-heating Temperature: 100°C
- Cure Time: 24 hours above 10°C
- Aftercare: PH neutral, Avoid wax or solvents
- Directional: Yes
- Tools: Soft squeegees with buffers
The protective cap should be peeled off before installation.
Important note: The images, colors, and finishes on the screen are approximate. For an accurate representation of the product, always check the color swatch. Rolls from the same production LOT number should be used for completing a wrap job as a slight batch-to-batch variation of color may occur. The film may scratch during the application or a day in and out use. The warranty does not cover the scratching of the film.
Colour selection: Screen colours vary by device and lighting. For colour-critical work, inspect a physical TeckWrap swatch before ordering. Professional preparation and installation are recommended.
Ordering with confidence
- Select the exact roll size or product variant shown above.
- Film rolls may require specialist freight because of their length and handling requirements.
- Colour appearance changes with light, viewing angle and screen calibration; a physical swatch is the final reference.
- Professional surface preparation and installation are recommended for wrap, PPF and tint films.
