Product overview
Plug & Play Power for Multi-Channel Factory Sound Systems
The MATCH PP 86DSP MK2 seamlessly continues the successful story of its predecessor while implementing several upgrades. As a high-performance 8-channel amplifier with a 1-channel line output and an integrated 9-channel DSP with 64 Bit power, it’s perfectly suited for audiophile upgrades of multi-channel factory sound systems , conveniently providing an impressive sound experience.
Seamless Integration and Impressive Connectivity
The MATCH Plug & Play concept ensures seamless integration with factory systems, which was uncompromisingly realized in the PP 86DSP MK2. With its impressive 2 Ohms stability across all amplifier channels, it effortlessly connects to nearly all OE speakers, while optional cable harnesses significantly facilitate integration into existing multi-channel factory sound systems. Furthermore, the MATCH PP 86DSP MK2 boasts enhanced connectivity, featuring an intelligent 6-channel highlevel input with the ADEP.3 circuit and a MEC slot for system expansions such as Bluetooth ® HD audio streaming. It also includes a 1-channel mono line output for connecting external amplifiers like the MATCH UP 1FX and an optical input in SPDIF format with a sampling rate between 12 and 96 kHz. Last but not least, it also comes with our SCP port for optional accessories like the DIRECTOR , CONDUCTOR etc.
Virtual Channel Processing – The Modern Way of Signal Routing
The optimal adaptation to existing multi-channel sound systems requires sensible management and configuration of the many DSP channels – so it was no question that the PP 86DSP MK2 is also equipped with Audiotec Fischer's innovative virtual channel processing. Especially when front, rear and center systems are split into multi-way systems, conventional routing concepts quickly reach their limits, both in terms of implementation and usability.
Virtual Channel Processing – The Modern Way of Signal Routing
The multi-stage "Virtual Channel Processing", in conjunction with the recognized user-friendly DSP PC-Tool software makes it easy to map even highly complex system configurations and to freely assign our proprietary FX sound features. Additionally, thanks to its generous number of channels in combination with the optional MEC ANALOG IN module, the PP 86DSP MK2 is also a prime example for applications where 1 to 1 routing (IOR) makes sense.
ACO – Advanced 32 Bit CoProcessor Plattform
Of course, the PP 86DSP MK2 is equipped with our proprietary 32 Bit ACO platform, which doesn’t just take over all control tasks ultra-fast, but also handles a bunch of audio functions: fantastic sound effects such as Augmented Bass Processing or Real Center are implemented as well as a channel-separated Input EQ including Input Signal Analyzer (ISA) for easy analysis and compensation of input signals of OE radios, which already include a sound setup by default.
DSP PC-Tool 5 feat. TuneEQ – Powerful features for the ultimate sound experience
Of course, the MATCH PP 86DSP MK2 can be easily configured via our professional and exceptionally intuitive DSP PC-Tool . The familiar, numerous setting options leave nothing to be desired and guarantee an extremely precise sound adjustment even for complex system configurations. And thanks to the proprietary TuneEQ function for automated frequency response correction, you also save a lot of time when optimizing your sound.
Key features
- High-performance 8-channel amplifier with 1-channel line output and integrated 9-channel DSP
- Perfect for upgrading multi-channel factory sound systems
- 2 and 4 Ohms stability on all amplifier channels – effortless connection to almost every OE speaker
- Optional cable harnesses for easy integration into existing multi-channel factory sound systems
- Extremely powerful 64 Bit “fixed point” Audio DSP
- ACO – Advanced 32 Bit CoProcessor platform for extended feature set
- ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals
- Proprietary TuneEQ function for automated adjustment of the output equalizers
- SFX (DSP Sound Effects) – Augmented Bass Processing, RealCenter & Co.
- Smart 6-channel highlevel input with ADEP.3 circuit and adjustable input sensitivity from 5 to 11 Volts
- VCP (Virtual Channel Processing) allows even more flexible configuration for highly complex sound systems
- MEC slot for system expansions like Bluetooth ® HD Audio Streaming, High Resolution Audio Streaming via USB etc.
- Optical input in SPDIF format with sampling rate between 12 and 96 kHz
- 1-channel line output for the connection of external amplifiers e.g. subwoofer amplifier MATCH UP 1FX
Technical specifications
| Technical data | |
|---|---|
| – @ 4 Ohms | 8 x 55 Watts |
| – @ 2 Ohms | 8 x 70 Watts |
| – @ 1 Ohm | – |
| – bridged @ 4 Ohms | – |
| – bridged @ 2 Ohms | – |
| – Subwoofer output @ 4 Ohms | – |
| – Subwoofer output @ 2 Ohms | – |
| Amplifier technology | Class HD |
| Inputs | 6 x Highlevel speaker input | 1 x Optical SPDIF (12 – 96 kHz) | 1 x MEC | 1 x Remote In |
| Input sensitivity | Highlevel 5 – 11 Volts |
| Input impedance RCA / Cinch | – |
| Input impedance highlevel | 9 – 33 Ohms with ADEP.3 |
| Outputs | 8 x Speaker output | 2 x RCA / Cinch (mono) | 2 x Remote Out |
| Output voltage RCA / Cinch | 3 Volts RMS |
| Frequency response | 20 Hz – 22,000 Hz |
| DSP resolution | 64 Bit |
| DSP power | 295 MHz (1.2 billion MAC operations/second) |
| Sampling rate | 48 kHz |
| DSP type | Audio signal processor |
| Signal converters | A/D: BurrBrown | D/A: BurrBrown |
| Signal-to-noise ratio digital input | 105 dB (A-weighted) |
| Signal-to-noise ratio analog input | 103 dB (A-weighted) |
| Distortion (THD) | < 0.015 % |
| Damping factor | > 100 |
| Operating voltage | 10.5 – 18 Volts (max. 5 sec.down to 6 Volts) |
| Power rating | DC 12 V ⎓ 40 A max. |
| Idle current | 685 mA |
| Max. remote output current | 500 mA |
| Operating temperature range | -40 °C to +70 °C |
| Fuse | 2 x 25 A LP-Mini-fuse (APS) |
| Additional features | Class HD technology with dynamically controlled | power supply, 32 Bit CoProcessor, ADEP.3 circuit, Smart Control Port, Start-Stop capability, USB, MEC slot, Auto Remote switch, galvanically isolated Line Outs |
| Dimensions (H x W x D) | 44 x 185 x 164 mm / | 1.73 x 7.28 x 6.46“ |
| Product properties | |
| Dimensions – width | < 200 mm, < 250 mm, < 300 mm, < 350 mm, < 400 mm, < 450 mm |
| Dimensions – depth | < 200 mm, < 250 mm, < 300 mm, < 350 mm, < 400 mm, < 450 mm |
| Dimensions – height | < 50 mm, < 60 mm |
| Output power @ 4 Ohms | > 30 Watt, > 50 Watt |
| Output power @ 2 Ohms | > 30 Watt, > 50 Watt |
| Load stability | 2 Ohm, 4 Ohm |
| Signal-to-noise ratio | > 80 dB, > 85 dB, > 90 dB, > 95 dB, > 100 dB |
| THD | < 0,05 %, < 0,1 %, < 0,2% |
| Advanced features | ACO platform, ADEP highlevel input, Auto remote switch, Integrated DSP, MEC slot, Regulated power supply, Smart Control Port, Start-Stop capability |
What you are ordering
The exact MATCH model shown above, APEX catalogue SKU M118003. Review the listed inputs, outputs, impedance and system requirements before ordering.
Technical information verified against the official Audiotec Fischer product page.
